Measure angle in Y axis (C axis)

After positioning, the touch probe measures in the direction of the Y axis. The touch probe must be positioned as centrally as possible at measuring depth at the first measuring point either manually or in automatic mode.

The calculated angle corresponds to the twist of the workpiece about the Z axis in relation to the X axis.

If no C axis is configured, call the cycle without transferring @P7. The twist in C can be manually transferred to the related zero offset by evaluating the output variables in the post-program.
